MOONDROP DAWN 4.4mm Dongle AMP/DAC is Available Now

by C G on Jun 10, 2022

Every sunset brings the promise of a new DAWN, that's beautiful and amazing!

Since MOONDROP announced their MOONRIVER 2, many fans wondered where MOONRIVER 1 was. As they mentioned in the release video of MOONRIVER 2, MOONRIVER 1 had released several years earlier, and gone because of the immature components in power consumption and compatibility. And here, what we bring is not the MOONRIVER series, but their new product, DAWN, a new mini reasonable full balanced DAC/AMP, and it's available now at at a affordable price tag of 69.99USD! Let's see what MOONDROP brought on DAWN!

DWAN 4.4mm is designed with aviation aluminum alloy CNC shell, It not only has rigidity, but also can shield external electromagnetic interference, with the white matte paint spraying, presenting delicate texture!

DAWN 4.4mm adopts dual CS43131 high performance decoding chip, and the full-link full balanced decoding is performed through four-channel, which bring super high-performance beyond the theoretical value of the chip. Besides that, It features the maximum power of 4Vrms, and offers up to 230mW undistorted power at 32Ω, it helps to drive all kinds of earphones easily.

Meanwhile, it has 132dB dynamic range, and the background noise is as low as 1.3uVrms. DAWN 4.4mm owns the capability of decoding DSD256 and PCM 32Bit/ 768kHz.

Furthermore, DAWN 4.4mm utilizes the customized parallel arrangement of high-purity copper silver-plated digital signal transmission cable to ensure the signal transmission, low distortion and anti-interference of digital signals.

Another bonus, DAWN 4.4mm is compatible with MOONDROP LINK APP for Android (iOs doesn't support), It can process the firmware upgrade (via PC), gain and filter settings (via smartphone).

Specifications:

Weight: 13.7g
Size: 120mm X 16.4mm
Earphone Jack: 4.4mm balanced port
Frequency response range: 7Hz-90kHz(-3dB)
Port: USB Type-C
Background noise: 13uV(AES17 20kHz)
THD+N: 0.00017% (AES17 20kHz, without load)
SNR: 132dB(AES17 20kHz,A-weight)
Firmware upgrade: Support (Connect PC)
Gain: High/Low (Software switching)
Line- out: 4Vrms(High,2Vrms(Low)
Maximum output power: 230mW@32Ω, 54mW@300Ω

Worries about the limitations of Lightning? No problem! It's said that the lightning adpater comes soon! More details pls find here or contact us directly via email or chat! Any question, suggestions and comments are welcome!
